Water Cooling Pump TA90E

High Flow Water Cooling Pump TA90E Features
120L high-flow for rapid coaling
Maximum pressure 3Bar, efficient working point 51L@23M
Intelligent frequency conversion control
Extreme low temperature cold starting at -40°C, stable flow
20,000 hours long lifetime

Typical Applications
Liquid cooled EV charging stations
Servers cooling
Chiller
Thermal management
Laser cooling
Medical cooling

Technical data

Model	TA90E-A48-12035
Motor Type	Brushless DC Motor
Ambient Temperature	-40～55℃
Liquid Temperature	-40~80℃
Media	Water, Antifreeze, Coolant, Glycol, Dielectric coolants. etc
Working Voltage	48V
Ideal Life Time	>20000 Hours
IP Level	IP67
Certification	CE, NSF, WRAS, REACH, ROHS, UL(UL certification in progress; UL-compliant customization capability available)
OD(inlet / outlet)	20mm / 20mm OEM Customization Available
Working Mode	Continuous
Bushing Type	High Wear Resistance Graphite Bushing
Power Supply	DC power supply
EMC	Good electromagnetic compatibility, low EMI and high immunity
Protection Function	Over-Voltage Protection, Lower-Voltage Protection, Dry-running Protection, Over-Temperature Protection, Over-Current Protection, Blocked-Protection, Polarity Protection, Constant Power Output
Functions	TA90 Supports PWM speed control and FG (RPM) signal feedback, enabling precise flow regulation and real-time performance monitoring.
Remarks	Can't dry-running, not self-priming



Model	Product Code		Max Water Flow (L/Min)	Rated Voltage(DC)	Rated Current (A)	Max Water Head(M)	Rated Power(W)
TA90E	TA90E-A48-12035		120	48VDC	7.3	36	350
