■ Overview
Application:
under sink hot water dispenser
Instant filtered boiling ,Chilled and sparkling water systems
Instant filtered drinking water systems
Coffee maker/coffee machine, Water cooler/water dispenser, Beverage dispenser
.jpg)
Product Features:
•.High efficiency brushless DC motor with long lifetime 20,000hours
•.Heavy duty work,can sustain continuous 24hours work
•.All wetted materials FDA approved to be safety usage
• High temperature resistance 100 degrees Celsius, stable flow
.jpg)
.jpg)
■ Specifications
| Max Flow Rate | 7.5L/MIN |
| Max Static Lift | 3.5 M |
| Rated Voltage | 24v |
| Food Grade(Y/N) | Y |
| Liquid Temperature | -40-100°C |
| Pump Theory | Centrifugal pump |
| Motor Type | Brushless DC motor |
| Ambient Temperature | -40-40°C |
| Media | Pure Water |
| Use Place | Indoor |
| Working Voltage Range | 12V-28V |
| Power Consumption | 10.8W |
| Ideal Life Time | 20000 Hours |
| Working Mode | Continuous |
| Power Supply | DC power supply, battery |
| Remarks | Can’t dry-running, not Self-priming |
■ Parameter
| Model | Product Code | Max Water Flow (L/Min) | Rated Voltage(DC) | Rated Current (A) | Max Water Head(M) | Rated Power(W) |
| B04 | TL-B04-A24-0803 | 7.5 | 24 | 0.45 | 3.5 | 10.8 |
■ Curve & Dimension
.jpg)
.jpg)
